| Adjustments |
Roller mechanism on seat adjustment provides smooth operation |
| Belts and Pulleys |
Heavy-duty belt system ensures smooth, even motion |
| Cushioning |
Pads are molded with radius on edge for improved comfort |
| Dimensions (L x W x H) |
48" x 58" x 80" (metric cm: 122 x 148 x 204) |
| Foot Platforms |
Polyethylene spray-coated for impact, corrosion, and abrasion resistance |
| Frame |
Each frame receives an electrostatic powder coat finish to ensure maximum adhesion and durability; 11-gauge steel frame ensures maximum structural integrity |
| Hand Grips |
Grips retained with aluminum collars, preventing them from slipping during use; Hand grips are an extruded thermo rubber compound that is non-absorbing and wear-and-tear resistant |
| Instructional Placards |
Easy-to-follow instructions illustrate proper use and muscles trained |
| Max User Weight |
300 lb (136 kg) |
| Product Code |
MTSFP |
| Recommended Live Area (D x W) |
60" x 82" (metric cm: 152 x 208) |
| Shrouds |
Full front and back shrouds and pulley covers |
| Weight |
793 lb (360 kg) |
| Weight Plates and Guide Rods |
Solid-steel weight plates. Top weight plate is fitted with self-lubricating bushings; 7/16" (11 mm) diameter weight selector pin magnetically locks in place and is connected to stack to prevent loss; Drop down incremental weight system |
| Weight Stack (includes increment weight) |
2 x 150 lb (2 x 75 kg) |
