Adjustments |
Roller mechanism on seat adjustment provides smooth operation |
Belts and Pulleys |
4-1/2" (11 cm) and 6" (15 cm) diameter fiberglass-impregnated nylon pulleys feature sealed bearings |
Cables |
7x19 strand construction, lubricated, nylon-coated cable meets U.S. military specifications |
Cushioning |
Pads are molded with radius on edge for improved comfort; All edges are stitched to eliminate any folds in the material that would limit durability |
Dimensions (L x W x H) |
49" x 56" x 71" (metric cm: 124 x 142 x 206) |
Foot Platforms |
Polyethylene spray-coated for impact, corrosion, and abrasion resistance |
Frame |
Each frame receives an electrostatic powder coat finish to ensure maximum adhesion and durability; Standard rubber feet protect base of the frame and prevent the machine from slipping; 11-gauge steel frame ensures maximum structural integrity |
Hand Grips |
Grips retained with aluminum collars, preventing them from slipping during use; Hand grips are an extruded thermo rubber compound that is non-absorbing and wear-and-tear resistant |
Instructional Placards |
Easy-to-follow instructions illustrate proper use and muscles trained; Axis of rotation marked with red indicator to help cue correct alignment |
Max User Weight |
300 lb (136 kg) |
Product Code |
HS-PEC |
Recommended Live Area (D x W) |
103" x 68" x 71" (metric cm: 261 x 173 x 180) |
Shrouds |
Standard rear shroud on SE models; Optional full front shroud on SE models |
Weight |
580 lb (263 kg) |
Weight Plates and Guide Rods |
Solid-steel weight plates. Top weight plate is fitted with self-lubricating bushings; 7/16" (11 mm) diameter weight selector pin magnetically locks in place and is connected to stack to prevent loss; Drop down incremental weight system (standard on SE models) |
Weight Stack (includes increment weight) |
295 lb (138 kg) |
